PC-3000 SSD固态硬盘数据恢复功能

The PC-3000 SSD Software System operates in tandem with one of the three up-to-date hardware platforms – PC-3000 Express, PC-3000 UDMA, or PC-3000 Portable – and it is intended for SSD repair and diagnosis and for data recovery from SSDs with SATA, PATA, mSATA, and M.2 (NGFF) interfaces and the capacity from 64 GB to 1 Tb produced by different manufacturers, such as OCZ, Corsair, Crucial, RunCore, A-DATA, G.Skill, Micron, Plextor, Intel, Samsung, Seagate, Kingston and others.

The PC-3000 SSD contains a set of specialized utilities for working with solid-state drives. This set includes the Universal Utility for diagnosing any SSD based on the ATA-8 specification (both currently existing models and those that will be manufactured in future) and the Active Utilities (Special Utilities) intended for working with a particular drive model in factory mode. It enables to deeply diagnose SSDs, to perform service operations, to re-write the drive's microcode, to get direct access to memory chips, to carry out low-level formatting blocking the damaged cells and placing their addresses into the defect table, and to perform many other useful operations.



verify and restore the SSD's service information

read and write the content of the SSD's ROM

load the microcode into the drives's RAM

emulate the translator operation in order to get access to user data

view the password and reset the password that was earlier set on an SSD

turn off background processes in an SSD to prevent data damage

provide direct access to the content of memory chips (it makes unsoldering unnecessary)

work with the Data Extractor

diagnose an SSD in factory mode

verify and restore the SSD's service information

read and write the content of the SSD's ROM

load the microcode into the drives's RAM

view the logs of hidden defects (P-page, G-page)

perform low-level formatting to hide the discovered defects

change the configuration and identification parameters

reset the logs and S.M.A.R.T. parameters

search for the damaged memory chips

The list of Active Utilities of the PC-3000 SSD System is expanded as soon as new SSD models are studied, and it is a continuous process. Those utilities that are currently available allow you to successfully recover data from all contemporary solid-state drives and to resolve the majority of wide-spread SSD problems. It is planned to add special adapters and connectors that will allow to use technological interfaces to diagnose and repair drives.

repair functions

data recovery functions

service and diagnostic functions

PC-3000 Express

PC-3000 UDMA-E - PC-3000 Portable

compatible with Data Extractor Express (RAID Edition)

compatible with Data Extractor UDMA (RAID Edition)

compatible with Data Extractor Portable

UDMA, PIO, Terminal

PATA,

SATA,

mSATA (if there is an adapter),

M.2 (NGFF) (if there is an adapter).

standard technological modes for SSD

the System's proprietary advanced technological modes

the possibility of working with dumps in the manual mode
