PC3000硬盘维修数据恢复工具5.9.21新增功能说明

he following English and Japanese PC-3000 software updates are available now:

PC-3000 SAS Ver.5.9.21

PC-3000 SSD Ver.2.0.1

Data Extractor Ver.5.2.26

Data Extractor RAID Edition Ver.5.2.26

Defect list editor for P List, TA List, Servo Flaws List has been added

Utility actions for Data Extractor:

   - RAM head map correction (it has become possible to set MaxHead, active physical and logical head maps)

   - loader usage (Update Microcode) (it has become possible to upload Diag and Tech overlays in RAM)

The capability of scanning the list of the last 32 RW commands to diagnose the errors of system file reading

Reading modules table and system file list via terminal for HDDs without readiness state

Added support for Self-Encrypting Drives with automatic data decryption

It has become possible to recover P-List from PST logs

Added SA regions editing in RAM - Support Malibu, Makalu 2.5 families

It has become possible to work with service area via SATA for SATA HDDs

Techno mode reading for HDDs with translation initialization error

The 02TSKB (3,5") family is now supported

Techno key has been added for Trinity architecture drives with "Apple" firmware

It has become possible to work with "physical" sectors of HHDs which have "Logical sector per physical sector" parameter more than 1

It has become possible to make "snapshots" using head map or legend

New operations have been added for maps in "Object Map" mode (consolidation, intersection, non-intersection, cutting, inversion, compression)

It has become possible to decrypt the sectors that were previously read without decryption

Auto-detection based on meta-data of: mdadm0.9, mdadm1.x, LDM, Promise Fastrack, and several extends of VMFS

Map and legend to estimate the state of sectors in virtual RAID

The functionality for indicating and editing block indices in Reed-Solomon sequence

Auto-detection for indices of Reed-Solomon sequence

It has become possible to recover two drives with two Reed-Solomon blocks

HUC1090xxCSxx family is now supported

Modules table can now be loaded

The following features have been added: system files reading/writing, Non Resident G-List editing/clearing, P-list editing, Non Resident Primary DST List editing

Editing of passport data when working with Flash ROM data

Corsair SSD Neutron Series Utility is added

OCZ Barefoot 3 Utility is added

The "if required" option for COM-port parameters has been added

For the "Work and edit HDD resources" mode and "Sector edit" mode, it has become possible to block the "Close" button until the reading process is finished

Added support for Self-Encrypting Device HDD with data decryption "on-the-fly"

Improved head map creation for latest families starting from Tressels

Added the plugin for 129, 130 modules and header searching for shifts which are different from sector size

Improved "Upload Dir Into RAM", it has become possible to load from file, and use LDR after DIR loading

Improved "Defect Lists Report"

Added SA regions editing mode in RAM

Support Malibu, Makalu 2.5 families

Support head map editing for Europa and Esprit families

Improved modules control sum checking for Orion and Aquarius families

Support RAM head map for drives with 10 heads

Plugin for ROM dump working (WD Marvel ROM map), it has become possible to extract/add ROM modules

The following features were added in the Edit HDD ID menu:

Edit serial number in ROM

Creation date and DCM editing

Firmware version editing

WWN editing

User password enabling/disabling and editing

Security level changing

Master password enabling/disabling and editing

Master password revision code editing

Self-Encrypting drive option enabling/disabling

It has become possible to edit the following fields:

Spin-up/Spin-down after power-up

Disable look ahead

Enable write cache

Support power-up in standby

Disable support UDMA all

Disable support UDMA 66 and above

Disable support UDMA 100 and above

Disable support UDMA 133

Support automatic acoustic management

Disable support automatic acoustic management

Enable automatic acoustic management

Disable security mode support

Disable host protected area

Enable relocation

The Edit HDD ID function has been added for RAM

The following drive commands have been added:

Techno ON/OFF

Firware restart

Warm reset

Spin down and reset

Spin up

Spin down

It has become possible to recover P-List from PST logs and to "Upload Dir in RAM" from file

WD Marvel USB/COM

Interrupt response (cancelling) current process via COM-port

Interrupt response reading/writing processes

Optional saving data at utility start via COM-port

WD Caviar, WD Caviar Cyl32, WD Caviar Cyl32 SATA, WD Marvel (non-ROYL HDD)

Control sum and header checking during modules reading

Main changes and new functionality:

Improved LBA to CHS conversion for manual recovering of translator. Following modes have become possible:

Host USER LBA -> CHS (new, based on: Media cache value, physical LBA alignment factor and physical sector size)

Native USER LBA -> CHS (old, LBA conversion as is)

Native System LBA -> CHS (old, LBA conversion as is)

The functionality for adding and editing defects in P-list, TA-list, and Servo Flaws list

Utility actions for DataExtractor:

RAM head map correction (it has become possible to set MaxHead, active physical and logical head maps)

Loader usage (Update Microcode) (it has become possible to upload Diag and Tach overlays in RAM)

DIC inhibit (Data Integrity Check) (inhibit power off/on during writing, speed up rate of reading for drives with BAD sectors)

The capability of scanning the list of the last 32 RW commands to diagnose the errors of system file reading

Improved password clearing for Momentus Thin drives (Julius1 / Yarra / Sapta)

The description of system files based on modules table

The capability of working with ROM dump with 1 MB size

For drives in busy state, following actions are now available at utility start:

Reconnect COM-port

HDD power supply

Give Soft reset

Give Hard reset

Re-read HDD ID

Give Boot Code mode initialization signal

Give command mode initialization signal

Completely optimized Safe Mode initialization procedure

Improved procedure of working with defect list from RDMT (G-list)

Improved algorithm of determining the PATA/SATA command set

Main changes and new functionality:

Improved procedure of HDD ID correction for drives of Trinity architecture

It has become possible to check the report of zone translation table (Work with Service area -> Zone Translation Table -> Report button)

New functionality for selecting heads to perform physical writing (Utility status -> Physical read -> Read only selected heads)

The "Edit head map in RAM" test has been improved. It is now possible to load the 9D PARAM_DM module from service area to RAM before editing

Techno key has been added for Trinity architecture drives with "Apple" firmware

Main changes and new functionality:

Access to data via SATA for the 29GSG, 46GSX, 52GSX, 55GSXF, 55GSXN, 55GSX, 56GSY, 59GSMP, 59GSM, 59GSXP, 59GSX, 61GSY, 63GSX, 64GSY, 65GSXN, 65GSX, 75GSX, 76GSX families. Access to data via terminal is also available. In "Utility Status" it's now possible to switch between different types of technomodes

The 02TSKB (3,5") family is now supported

P-list loading from file is now possible when the "reading via PBA" option is used in active utility mode

CP-DD Plugin for CP direction mode

Reading during translation initialization error for Techno-ON mode

Improved SMART clearing

It has become possible to hide defects in P-List instead of G-List for LBAs more than 1073741823

HUC1090xxCSxx family is now supported

Modules table can now be loaded from CP 82

      The following features have been added for the Cheetah 15K.7, Cheetah NS.2, Barracuda ES.2, Savvio 10K.3, Savvio 10K.4, Savvio 15K.2, Constellation, Constellation ES, Constellation ES.2 families:

System Files reading/writing

Non Resident G-List editing and clearing

P-list editing

Non Resident Primary DST List editing

      The following feature has been added for Cheetah 15K.6, Cheetah 15K.7, Cheetah NS.2, Barracuda ES.2, Savvio 10K.3, Savvio 10K.4, Savvio 15K.2, Constellation, Constellation ES families:

Editing of passport data when working with Flash ROM data (Tools->Utility extensions->Work with Flash ROM image)

      The following feature has been added for Savvio 10K.5, Savvio 15K.3, Constellation.2, Constellation ES.2 families:

Editing of passport data and head map when working with Flash ROM data

PC-3000 RAID Edition

Main changes and new functionality:

"Row Shift" parameter for RAID 5, RAID 5EE, and RAID 6 levels, which allows to move the table by certain number of rows

Map and legend to estimate the state of sectors in virtual RAID

The functionality for indicating and editing block indices in Reed-Solomon sequence

Auto-detection based on meta-data of: mdadm0.9, mdadm1.x, LDM, Promise Fastrack, and several extends of VMFS

Auto-detection for indices of Reed-Solomon sequence

It has become possible to recover two drives with two Reed-Solomon blocks

RAID 6 level detection for mdamd (table is line shifted)

Main changes and new functionality:

New legend for decrypted sectors

It has become possible to decrypt the sectors that were previously read without decryption

For virtual file system based on results of Scan MFT or Partition analysis, it has become possible to make "snapshots" using head map or legend, which allows to separate files with bad sectors from "fully read files" (all sectors are green) depending on parameters setting

Changes in the DRQ control and its options that have helped to speed up the rate of reading/writing for Express and UDMA-E

New type of files in RAW recovery mode

Improved algorithm of search in "Quick disk analisys" mode

EXT4 file system: It has become possible to results of uncompleted partition analysis for RAID recovering

UFS file system: It has become possible to results of uncompleted partition analysis for RAID recovering

XFS file system: ABTB and ABTC blocks have been added to the metadata map, Sparsed files are supported now, Map of XFS metadata for sector size > 512 bytes is supported now

HFS+ file system: detemination of block size in Partition Scan mode (if Volume Header is missing)

Spared files are now supported in XFS

New feature of the sector editor: a small white marker at the right bottom corner that indicates the "empty" sectors (sectors filled by zeros)

New operations have been added for maps in "Object Map" mode

consolidation of two maps

intersection of two maps

non-intersection of two maps

cutting one map from other

map inversion

map compression

Comments for chains in "Object Map" mode now can be cleared

SATA cable control for the drives connected directly to PC3000 ports

Main changes and new functionality in PC-3000 SSD version 2.0.1:

Corsair SSD Neutron Series Utility is added

OCZ Barefoot 3 Utility is added:

NAND Flash Memory chip ID testing

Dump saving feature for NAND Flash Memory chips

Now it is possible to work with NAND Memory chips from DE task

New form "Utility Status"

New tests for switching a drive from the "Safe" mode into "Normal" mode

Error handling during data readout from a drive

Correct initialization of SSD after power reset

New test for unlocking and cleaning password information for the drives which are operated in "Normal" mode

Bug fixes for drives with 512GB capacity
